| Unit Price: | USD 198000 / Set/Sets |
|---|---|
| Payment Type: | L/C,T/T,D/P,Paypal,Money Gram,Western Union |
| Incoterm: | FOB,CFR,CIF,FCA,CPT |
| Min. Order: | 1 Set/Sets |
| Delivery Time: | 3 Days |
Download:
Basic Info
Model No.: GZL-40
Application: Freezer Parts
Parts: Other
Ultimate Vaccum Degree: ≤5pa
Shelf Temp. Range: -50℃~+80℃
Cold Trap Temp.: ≤-75℃
Cooling Mode: Water Cooled
Defrosting Mode: Water Soaked
Shelf Dimensions: 1500*1800mm
Shelf Numbers: 15+1pcs
Shelf Spacing: 400mm
Freeze Drying Area: 40.5㎡
Ice Collecting Capacity: ≥800KG/24h
Additional Info
Packaging: Standard export packing
Productivity: 100
Brand: MINGYI
Transportation: Ocean,Land,Air,ARAMEX
Place of Origin: China
Supply Ability: 100
Certificate: ISO, CE
HS Code: 8419399010
Port: Shanghai,Qingdao,Tianjin
Product Description
GZL-40 mushroom lyophilization machine is a large scale lyophilization machine/lyophilizer.It could give more support to factory who has large production. GZL-40 Vacuum Freeze Dryer has quality material, good structure and famous brand vacuum pump and compressor. It should be the best choice for many users. Welcome customers from all over the world come to visit our factory and establish long term cooperation.
| Models | unit | GZL-40 mushroom lyophilization machine |
| freeze drying area | m2 | 40.5 |
| shipping weight | kg | 400 |
| shelf numbers | layers | 15+1 |
| shelf dimensions | mm | 1500*1800 |
| shelf spacing | mm | 80 |
| temperature range | ℃ | -50~+80 |
| ice collecting capacity | kg/B | ≥800 |
| cold trap temperature | ℃ | ≤-75 |
| cooling mode | - | water cooled |
| defrosting mode | - | water soaked |
| ultimate vacuum | Pa | ≤5Pa |
| power | kw | 185 |
| dimensions | mm | 9400*2400*4500 |
| overall weight | kg | 20000 |
Main features of GZL-40 mushroom lyophilization machine
1.The shelves of GZL-40 Freeze Dryer are made with unique patented technology, high pressure resistance, high flatness, and good temperature uniformity.
2. The cooling speed of GZL-40 vacuum freeze dryer can be controlled throught The freeze-drying curve optimization control technology in the pre-frozen phase, and at the same time, the sample heating speed and the current vacuum value also can be controlled in the sublimation and analytical drying stages.
3. GZL-40 Vacuum Lyophilizer has patented gas diversion design and control technology ,strong ice collecting capacity and high drying efficiency.
4. GZL-40 freeze dryer has highly efficient mixed refrigerant medium, lower freezing point and higher boiling point, high heat exchange efficiency.
5. GZL-40 Production Type Freeze Dryer has vacuum adjustment during drying operation to avoid foaming and blowing of special materials and improve drying efficiency.
6. GZL-40 mushroom lyophilization machine has industrial-grade embedded touch screen + dedicated SH-HPSC-IV modular controller, stable and reliable system, high control accuracy.
7. GZL-40 High Quality Freeze Dryer has professionally designed LYO-CONTROL control system that can save multiple sets of process . At the same time, the process can be adjusted in real time during the drying process to improve the process optimization rate.
8. Flexible manual + automatic control mode, the manual for groping process, and the automatic for batch production.
9. The powerful LYO-MEGA host computer control system can record and save the operating data, curves and alarm records for ten years to improve the traceability of products; at the same time, it is convenient for observation, operation and fault diagnosis.
10. User grades and passwords can be set, and operations can be decentralized
11. The non-stardarded can be customized as requested.
